Leaf Structure

1
Leaf Structure Function
2
Leaves

• Structure is optimized for
• Absorbing light
• Carrying out photosynthesis

3
Leaves
Leaf Shapes Most of a leaf consists of a blade
attached to the stem by a petiole. The blade of a
simple leaf (left) can be different shapes. In a
compound leaf (right), the blade is divided into
many separate leaflets.
4
(No Transcript)
5
Leaf Functions - Photosynthesis

• Mesophyll spongy palisade site of
  photosynthesis
• Stomata pore-like openings that allow CO2 and
  O2 to diffuse into and out of leaf
• Guard cells each stoma consists of two
  controls opening and closing of stomata as a
  response to water pressure

6
Transpiration

• Water evaporates easily from leaf surfaces due to
  diffusion
• Transpiration is the loss of water through a
  plants leaves
• Water must be replaced by water drawn up from
  roots through the xylem vessels

7
Gas Exchange

• Plants keep their stomata open just enough to
  allow photosynthesis to take place but not so
  much that they lose an excessive amount of water

8
Gas Exchange

• When water pressure in guard cell is high, outer
  walls of cells forced into curved shape. This
  pulls inner walls away from one another, opening
  the stoma.
• Reverse happens when water pressure is low.
• Influenced by wind, temperature, time of day

9
(No Transcript)
10
Guard Cells
11
Stomates
12
Guard Cells
13
Rate of Photosynthesis
Amount of Water
Night Day Night
14
Cellular Respiration
Rate of Photosynthesis
Night Day Night
15
Water Transport in Plants

• Water is transported through plants by a
  combination of
• Capillary action
• Root pressure
• Transpiration

16
Capillary Action

• Cohesion - water molecules are attracted to each
  other
• Adhesion attraction of unlike molecules
• Capillary action water molecules are attracted
  to walls of tube (xylem) and to each other.
  Thinner the tube the higher the water will rise.

17
Capillary Action Capillary actionthe result of
water molecules ability to stick to one another
and to the walls of a tubecontributes to the
movement of water up the cells of xylem tissue.
As shown here, capillary action causes water to
move much higher in a narrow tube than in a wide
tube.
18
Transpiration

• Loss of water from leaves pulls water up the
  plant transpirational pull.
• The hotter and drier the air, the windier the
  day, the more water is lost and the more water is
  pulled up from the roots
• If there is not enough water to replace water
  lost, wilting will occur

19
Movement of Water Through a Plant.  Root
pressure, capillary action, and transpiration
contribute to the movement of water within a
plant. Transpiration is the movement of water
molecules out of leaves. The faster water
evaporates from a plant, shown in A, the stronger
the pull of water upward from the roots, shown in
B.
