Title: TNM Pilot Projects


1
The National Map
Progress and Plans
U.S. Department of the Interior U.S. Geological
Survey
2
National Spatial Data Infrastructure (NSDI)
NSDI is The technologies, policies, and people
necessary to promote sharing of geospatial data
throughout all levels of government, the private
and non-profit sectors, and the academic
community
3
National Spatial Data Infrastructure (NSDI)
Executive Order 12906
  • Reduce duplication of effort among agencies
  • Improve quality and reduce costs related to
    geographic information
  • Make geographic data more accessible to the
    public
  • Increase the benefits of using available data
  • Establish partnerships across sectors
  • The Federal Geographic Data Committee (FGDC) is
    the coordination body for developing the NSDI

4
The Need for the National Map
Federal Geographic Data Committee Webpage Much
has been accomplished in recent years to further
the implementation of the NSDI, but there is
still much to be done to achieve the vision of
current and accurate geographic data being
readily available across the country.
Data sets often
  • Are in different formats and projections
  • Do not align with one another over an area
  • Do not match across jurisdictional boundaries
  • Are not up-to-date

5
The National Map Initiative
  • Ensure the data are current
  • Make the data easily accessible online
  • Target date is 2010

6
The National Map Data Content
  • Orthorectified imagery
  • Land characterization
  • Elevation
  • Vector layers
  • Transportation
  • Hydrography
  • Structures
  • Boundaries
  • Geographic names

7
The National Map Data Characteristics
  • Seamless
  • Consistently classified
  • Variable resolution, completeness
  • Consistency and integration among themes of data
  • Current to within seven days
  • Metadata
  • Available online 24-7

8
The National Map Depends on Partnerships
How will we achieve this goal?
  • In collaboration with other governmental
    agencies, academia, the private sector, and
    volunteer groups, use the best available data
  • The USGS will serve as the coordinator,
    integrator, and, where needed, producer of core
    geographic framework data responsible for
    awareness, availability, and utility

9
The National Map Strategy
  • The initial strategy is to begin with
    proof-of-concept pilot projects to address
    technical and partnership questions in
    manageable, achievable phases
  • The pilots are the foundation upon which future
    partnerships for data sharing and maintenance
    will be built
  • Pilots will show results by October, 2002

10
Fiscal Year 2002 Pilot Projects
11
Fiscal Year 2002 Pilot Projects
Washington-Idaho
Pennsylvania
Utah
Missouri
Delaware
Texas
US Landsat
LAKE TAHOE AREA
12
Lake Tahoe Area
13
Lake Tahoe Area
Data Providers
  • Local
  • Carson City
  • City of South Lake Tahoe
  • Carson City
  • Douglas County
  • El Dorado County
  • Nevada County
  • Washoe County
  • Regional
  • Tahoe Regional Planning Agency
  • State
  • California Resources Agency
  • CalTrans
  • Nevada Department of Transportation
  • Federal - U.S. Forest Service
  • Lake Tahoe Basin Management Unit
  • El Dorado National Forest
  • Geospatial Service and Technology Center

14
Lake Tahoe Area Imagery
  • USGS 1 meter Digital Orthophotos (DOQs) will
    serve as the core imagery dataset for the Pilot
  • A DOQ is a digital image of an aerial photograph
    in which displacement caused by camera
    orientation and terrain have been removed

15
Lake Tahoe Area Data Imagery
USGS produced new DOQs from 1999 photography to
replace 1993 and 1994 vintage data
16
Lake Tahoe Area
DOQs have been mosaicked to 7.5 quadrangles for
use in integration and online display
17
Lake Tahoe Area Imagery
Landsat 7 Enhanced Thematic Mapper Plus (ETM) is
a multispectral scanning radiometer that provides
data from eight spectral bands
Resolution visible and near-infrared (bands
1-5 and 7) 30 meters panchromatic (band 8)
15 meters thermal infrared (band 6) 60 meters
18
Lake Tahoe Area Imagery
SPOT - SPOT IMAGE Corp. Panchromatic (black and
white) data at a resolution of 10 meters per
pixel The image was provided through the
multi-agency/multi-sector license arranged by the
California Resources Agency
19
Lake Tahoe Area Imagery
  • ASTER - Advanced Spaceborne Thermal Emission and
    Reflection Radiometer provides 14 spectral bands
    with 15- to 90-meter resolution

20
Lake Tahoe Area Elevation
10 Meter National Elevation Dataset (NED) will
serve as the core elevation dataset for the Pilot
21
Lake Tahoe Area Elevation
A seamless, multi-source, multi-resolution
elevation database is compiled from the "best"
available DEM data
  • Identification of Existing DEM's
  • Artifact Corrections
  • Datum and Elevation Unit Conversions
  • DEM Paneling
  • Projection Transformation
  • Merge of Multiple Data Sources
  • Edge Matching
  • Metadata Documentation
  • Accuracy Verification and Revision
  • Original resolution 30 meters

22
Digital Elevation Model Resolution
30 meter resolution
10 meter resolution
23
Lake Tahoe Area Elevation
  • City of South Lake Tahoe LIDAR
  • Bathymetry sonar and LIDAR

Gardner, et al. 1998. USGS Open File Report
98-509.
24
Lake Tahoe Area Land Cover
  • National Land Cover Data (NLCD) classified from
    30 meter Landsat Thematic Mapper imagery of 1992
  • Developing high-resolution land cover data for a
    limited subset of project area

25
National Hydrography Dataset (NHD)
Lake Tahoe Area Hydrography
  • National dataset describing surface water
    features
  • NHD is based on geometry of USGS Digital Line
    Graphs (DLGs) integrated with attributes from the
    Environmental Protection Agency Reach File
    Version 3 (RF3)
  • Reach codes are unique identifiers for each
    stream segment
  • Attributes include flow direction and names
  • Based on 1100,000-scale data but designed to
    integrate and encourage the development of higher
    resolution data
  • Data are seamless across watersheds

26
http//nhd.usgs.gov
27
(No Transcript)
28
Lake Tahoe Area Hydrography
1100,000-Scale data are available 124,000-Scale
NHD partnership with Forest Service Region 5
29
Lake Tahoe Area Transportation
  • Forest Service Region 5
  • City of South Lake Tahoe
  • Washoe and Douglas Counties

30
Lake Tahoe Area Structures
  • USGS project to map structures
  • Use local ancillary data including

Cadastral data Address points South Lake Tahoe
LIDAR data
31
Lake Tahoe Area Boundaries and Names
Boundaries
  • Forest Service Region 5
  • Local Data
  • USGS Digital Line Graph (DLG) boundary overlays

Geographic Names
  • Geographic Names Information System (GNIS)
  • Other sources (for example, road names)

32
Lake Tahoe Area
Clearinghouse capability
Downloadable zip files for Tahoe Basin data
33
Lake Tahoe Area
Established an Internet Map Server
34
Lake Tahoe Area
Integrate the Lake Tahoe Area Pilot with Tahoe
Regional Planning Agencys (TRPAs) Tahoe
Integrated Information Management System (TIIMS)
35
Lake Tahoe Area Lessons Learned
Transportation Example
  • Data ingested in varying formats from four
    counties, Nevada Dept. of Transportation,
    Caltrans, Forest Service, USGS
  • Data quality varied greatly, even within datasets
  • Overlapping data had to make choices about
    which source to use where
  • Gaps in coverage filled in with USGS Digital
    Line Graph and Forest Service Cartographic
    Feature File data

36
(No Transcript)
37
Lake Tahoe Area Lessons Learned
Transportation Example Conclusions
  • Without consistent data models, integration is a
    lot of work
  • If we continue in the same vein, maintenance will
    take a similar amount of work
  • If maintenance takes that much work, we wont get
    The National Map built any time soon

38
Reintegrate data
39
(No Transcript)
40
Lake Tahoe Area Future Directions
  • Convert to Geodatabase model to test versioning
    and allow for more efficient updates
  • Develop agreements with partners for data
    maintenance
  • Continue to advance the datasets and
    functionality of the website
  • Integrate The National Map with TRPAs TIIMS

41
Future Directions
Beyond the Pilot California Implementation
  • Start with existing statewide datasets
  • Jointly develop the California Spatial
    Information Library (CASIL) and the California
    National Map implementation
  • Determine roles for maintenance
  • Continue developing framework data
  • Develop a strategy for bringing in local data
    through regional councils

42
(No Transcript)
43
Fiscal Year 2002 Pilot Projects
44
Delaware
  • USGS National Map - Delaware Data Mapping and
    Integration Laboratory (DataMIL) Project
  • Offer the best available State and USGS
    geospatial data statewide identify and resolve
    data integration issues update each others
    data
  • Partners are University of Delaware, Delaware
    Geological Survey and Delaware Office of State
    Planning Coordination
  • Provide a user feedback mechanism

45
Delaware
http//www.datamil.udel.edu/nationalmappilot/
46
Texas
  • Texas Natural Resources Information System
    (TNRIS) and its network of state, county, local
    and private partners
  • Initial project area is 5 quadrangles in the
    Brownsville area, near the Texas Mexico border
  • Include data from INEGI, the Mexican mapping
    agency, and the city of Matamoros through a
    bi-national agreement with Mexico

47
Utah
  • Focus on the transportation data theme in one
    urban and one rural county in Utah
  • Collaborative effort between the USGS, the State
    of Utah Automated Geographic Reference Center
    (AGRC), and Grand and Salt Lake counties
  • To test The National Map concept for providing
    transportation data for emergency response,
    census requirement and other State and local
    government functions
  • Provide data and map products online

48
Moab, Utah Prototype Map
Utah
49
Missouri
  • Partners City of Cape Girardeau, Cape Girardeau
    County, USGS National Geologic Cooperative
    Mapping Program
  • Four 7.5-minute quadrangles in the Cape Girardeau
    area, located within the New Madrid seismic zone
  • Integrate The National Map with geologic data
    including bedrock geology, surficial geology,
    geologic fault lines, and historic geologic maps

50
Pennsylvania
  • PA Bureau of Topographic and Geologic Survey,
    Susquehanna Economic Development Area Council of
    Governments (SEDACOG), Southwestern Pennsylvania
    Commission (SPC), and Lancaster County
  • Collaboratively develop high-resolution
    orthoimagery and 124,000-scale National
    Hydrography Dataset (NHD), integrate local
    boundary and transportation data. Integrate
    large-scale land cover data with local parcel and
    zoning data for watershed management

51
Washington-Idaho
  • Four counties, each with widely varying levels of
    local GIS sophistication (144 7.5-min
    quadrangles)
  • Test multiple methodologies to engage partners in
    data sharing opportunities, including data
    exchange, work share, joint funding, assistance
    award, and direct data purchase
  • Work with University of Idaho to develop and
    coordinate the IMS implementation

52
US LANDSAT
EROS Data Center archives and distributes USGS
national geospatial datasets
53
US LANDSAT Goals
  • Provide useful online national reference
    information for map applications at a scale of
    1100,000 or smaller
  • Provide a web-enabled database of best available,
    current Landsat 7 orthoimagery for the entire US
    along with other national datasets including the
    National Hydrography Dataset, Geographic Names
    Information System Data, and a GDT roads dataset
  • Keep the database current to within one year

54
US LANDSAT Status
  • Over 700 Landsat scenes have been resampled to a
    1 arc-second (approx. 30 meter) sample interval
    in a Geographic Coordinate System using the North
    American Horizontal Datum of 1983
  • 3 of the 8 spectral bands have been selected,
    band 4 (near IR), band 3 (red), and band 2
    (green) that are displayed as red, green, and
    blue respectively, generating a 24-bit color
    infrared composite

55
Status
  • Overlap and sidelap have been eliminated each
    pixel location will be assigned to a single path
    and row

US LANDSAT
56
Duluth, MN Sub-Scene
  • Landsat7
  • Color IR (bands 4,3,2)
  • Path 27
  • Row 27
  • NHD, GNIS, GDT roads overlays

57
Future Directions
  • Expand partnerships
  • Develop paper map output capability
  • Identify data stewards/maintenance - establish
    agreements to document responsibilities for each
    data theme
  • Establish standards agreements
  • Enhance Internet map service functionality
  • Continually evaluate The National Map

58
Pilot Status
59
Pilot Status
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
Beyond the Pilots
  • Expand from pilots to develop a nationwide
    program
  • Document lessons learned and make plans
    accordingly
  • Start with well-organized states with
    standardized framework data and maintenance plans
  • Each level of government has a role in the
    success of the National Map look to the states
    to help facilitate our link to local data and
    provide statewide standards
  • Identify partner incentives and customize to
    state and local needs

66
Ongoing Review
  • Public comment on vision and products
    nationalmap.usgs.gov
  • Recent review of The National Map goals,
    approaches, and benefits by the Mapping Sciences
    Committee of the National Research Council
  • External review of 5-year strategic plans
  • Continuously review and reassess The National Map
    vision to update and add clarity to the concepts
    and strategic objectives

67
Federal Homeland Security
USGS The Nations Civilian Mapping Agency
  • Mission to ensure geographic information over the
    United States and its Territories
  • Focus on public domain data
  • Executive Order 12656 and Presidential Decision
    Directive-63
  • Connect the U.S. Defense community with domestic
    geographic infrastructure

68
Federal Homeland Security
National Imagery and Mapping Agency (NIMA) The
Nations Defense Mapping Agency
  • Mission to provide geographic information and
    services to U.S. Defense Agencies in support of
    national security objectives
  • Focus in the past has been on classified
    information for foreign intelligence
  • Has requested USGS support on domestic geographic
    information

69
Federal Homeland Security
Geospatial Assurance
  • Guarantee seamless, interoperable information
    environment that is current and accurate
  • USGS-NIMA-FGDC

70
Federal Homeland Security
USGS support of NIMA
  • Obtain or produce 1 foot color imagery for high
    priority cities where imagery is not current
    within a year
  • Cities, Counties and COGs have been contacted for
    existing data or partnership opportunities
  • Also need to gather existing critical
    infrastructure data

71
Federal Homeland Security
72
Federal Homeland Security
73
Federal Homeland Security
USGS Partnership with California
  • USGS recognizes that state and particularly local
    agencies hold key high-resolution datasets
  • The State is the appropriate facilitator of data
    from local agencies to the federal level
  • Goal is to meet federal, state and local needs
    through cooperative planning and implementation

74
The National Map Find us on the Web
at http//nationalmap.usgs.gov
75
Useful Websites
National Map nationalmap.usgs.gov California
Spatial Information Library www.gis.ca.gov USGS
satellite, landcover and other data
edc.usgs.gov National Hydrography Dataset
nhd.usgs.gov National Elevation Dataset
edcnts12.cr.usgs.gov/ned/ Tahoe Clearinghouse
tahoe.usgs.gov Delaware DataMIL www.datamil.udel
.edu/nationalmappilot/
Write a Comment
User Comments (0)
About PowerShow.com
