Adaptive Meshes on the Sphere: CubedSpheres versus LatitudeLongitude Grids

1
Adaptive Meshes on the Sphere Cubed-Spheres
versus Latitude-Longitude Grids

• Christiane JablonowskiUniversity of
  MichiganAmik St-Cyr
• NCARICON Friends Workshop, May/31/2007

2
Acknowledgments

• The AMR comparison is based on a joint paper with
  Amik St-Cyr and collaborators from NCAR,
  submitted to Monthly Weather Review, revised in
  May 2007
• The AMR Spectral Element Model was mainly
  developed by Amik St-Cyr, John Dennis Steve
  Thomas (NCAR)
• The AMR FV model is documented inJablonowski
  (2004), Jablonowski et al. (2004, 2006)
• Contributors to the AMR FV model areMichael
  Herzog (GFDL) Joyce Penner (UM)Robert Oehmke
  (NCAR) Quentin Stout (UM)Bram van Leer (UM)
  Ken Powell (UM)

3
Overview

• Computational Grids on the Sphere
• Adaptive mesh refinement (AMR) techniques
• Why are we interested in variable resolutions /
  multi-scales?
• Overview of two AMR shallow water models
• Finite volume (FV) model
• Spectral element model (SEM)
• Results Static and dynamic adaptations
• 2D shallow water experiments
• Conclusions and Outlook

4
Latitude-Longitude Grid

• Popular choice
• Meridians convergepolar filters or/andtime
  steps
• Orthogonal

5
Platonic solids - Regular grid structures

• Platonic solids can be enclosed in a
  sphereSource Wikipedia

6
Cubed Sphere Geometry
Advection of a cosine bell around the sphere (12
days)at a 45o angle
Courtesy of Ram Nair (NCAR)
7
Adaptive Mesh Refinements (AMR)
Latitude-Longitude gridModel FV
Cubed-sphere gridModel SEM
8
SEM Grid Points within Spectral Elements
Circles Gauss-Lobatto-Legendre (GLL) points for
vectorsSquaresGauss-Lobatto (GL) points
forscalarsElements are split in case of
refinements
9
FV Block-Structured Adaptive Mesh Refinement
Strategy
Self-similar blocks with 3 ghost cells in x y
direction
10
Other AMR Grids
Model ICONIcosahedral grid with nested
high-resolution regionsunder development at
the German WeatherService (DWD) and MPI, Hamburg
Source DWD, MPI
11
Features of Interest in a Multi-Scale Regime
Hurricane Frances
Hurricane Ivan
September/5/2004
12
High Resolution Multi-Scale Interactions
10 km resolution
W. Ohfuchi, The Earth Simulator Center, Japan
13
Shallow Water Equations
Momentum equation in vector-invariant form
Continuity equation
only in FV
vh horizontal velocity vector? relative
vorticityf Coriolis parameterK 0.5(u2 v2)
kinetic energyD horizontal divergence, ? damping
coefficienth depth of the fluid, hs height of
the orographyg gravitational acceleration
14
Finite Volume (FV) Shallow Water Model

• Developed by Lin and Rood (1996), Lin and Rood
  (1997)
• 3D version available (Lin 2004), built upon the
  SW model
• hydrostatic dynamical core used for climate and
  weather predictions
• Currently part of NCARs, NASAs and GFDLs
  General Circulation Models
• Numerics Finite volume approach
• conservative and monotonic transport scheme
• upwind biased 1D fluxes, operator splitting
• van Leer second order scheme for time-averaged
  numerical fluxes
• PPM third order scheme (piecewise parabolic
  method)for prognostic variables
• Staggered grid (Arakawa D-grid), C grid for
  mid-time levels
• Orthogonal Latitude-Longitude computational grid

15
Spectral Element (SEM) Shallow Water Model

• Documented in Thomas and Loft (2002), St-Cyr and
  Thomas (2005), St-Cyr et al. (2007)
• 3D version available
• Experimental tests within NCARs Climate Modeling
  Software Framework
• Numerics Spectral Elements
• Non-conservative and non-monotonic
• Allows high-order numerical method
• Spectral convergence for smooth flows
• GLL and GL collocation points
• Non-orthogonal cubed-sphere computational grid

16
Overview of the AMR comparison

• 2D shallow water tests (Williamson et al., JCP
  1992)
• Dynamic refinements for pure advection
  experiments
• Slotted cylinder
• Cosine bell advection test (test case 1)
• Static refinements in regions of interest (test
  case 2)
• Dynamic refinements and refinement criteria
  Flow over a mountain (test case 5)
• Rossby-Haurwitz wave with static refinements
  (test case 6)
• Barotropic instability test (Galewsky et al.,
  Tellus 2004)

17
AMR Transport of a Slotted Cylinder
Model FV
18
Transport of a Slotted Cylinder
SEM
FV
5 x 5 deg base grid, 3 refinement levels
19
Transport of a Slotted Cylinder
SEM
FV

• Slotted cylinder is reliably detected and
  tracked
• Over- and undershoots in SEM, FV monotonic

20
Snapshots Advection of a Cosine Bell
SEM
FV
21
Snapshots Advection of a Cosine Bell
SEM
FV
22
Error norms Cosine Bell Advection
Days
Days
Rotation angle ? 45Errors in SEM are lower
than in FV
23
Error norms after 12 days
Rotation angle ? 0SEM produces
undershootsErrors arecomparable
24
Snapshots Cosine Bell at day 3
North-polar stereographic projection at day 3 for
a 90
Uniform distribution in SEM, Convergence of
blocks in FV
25
2D Static Adaptations
Test case 2, ? 45

• Height field at day 14
• Smooth flow through refined region

26
Error norms Test case 2
Days
Days
Rotation angle ? 45Errors in FV partly due to
errors at AMR interfaces
27
2D Dynamic adaptations in FV
Vorticity-basedadaptation criterion
2D shallowwater test 515-day run
28
Snapshots Flow over a mountain
Geopotential height field (test case 5)
Longitude
Longitude
29
Snapshots Flow over a mountain
Geopotential height field (test case 5)
SEM
FV
30
Error norms Test case 5
Hours
Hours
Errors in SEM converge quicker to the reference
solution (T426 NCAR spectral model, provided by
DWD)
31
Snapshots Rossby-Haurwitz Wave
Geopotential height field (test case 6) at day 7
Smooth flow through static refinement regions
32
Barotropic instability test case
Convergence analysis Relative vorticity at day 6
1.25 resolution is needed to get a good
representation of the wave
33
Barotropic instability test case
Convergence analysis Relative vorticity at day 6
Second highest and highest resolutions are very
similar to each other, SEM and FV are similar
34
Barotropic instability test case
Vorticity-based adaptation criterion Day 3 and 4
5 deg base grid, 4 refinement levels
35
Barotropic instability test case
SEM and FV are very similar
36
Alternative AMR Unstructured Triangular Grid
Hurricane Floyd (1999)
OMEGA model Courtesy ofA. Sarma (SAIC, NC, USA)
Colors indicate the wind speed
37
Conclusions

• Both grids, cubed-sphere meshes and
  latitude-longitude grids, are options for AMR
  techniques
• SEM model shows lower error norms in comparison
  to FV
• Mainly due to high-order numerical method
• Partly due to different AMR approach that does
  not need interpolations of ghost cells in
  blocks
• But SEM is non-monotonic and non-conservative
• Cubed-sphere grid has clear advantages
• No convergence of the meridians, no polar filters
• But, GLL and GL points for numerical method in
  SEM are clustered along boundaries of spectral
  elements
• SEM requires very small time steps
