How to Read a Head CT

1
How to Read a Head CT

• (or How I learned to stop worrying and love
  computed tomography)

2
Andrew D. Perron, MD, FACEP

• EM Residency Program Director
• Department of Emergency Medicine
• Maine Medical Center
• Portland, ME

Andrew D. Perron, MD, FACEP
2
3
Head CT

• Has assumed a critical role in the daily practice
  of Emergency Medicine for evaluating intracranial
  emergencies. (e.g. Trauma, Stroke, SAH, ICH).
• Most practitioners have limited experience with
  interpretation.
• In many situations, the Emergency Physician must
  initially interpret and act
• on the CT without specialist assistance.

4
Head CT

• Most EM training programs have no formalized
  training process to meet this need.
• Many Emergency Physicians are uncomfortable
  interpreting CTs.
• Studies have shown that EPs have a significant
  miss rate on cranial
• CT interpretation.

5
Head CT

• In medical school, we are taught a systematic
  technique to interpret ECGs (rate, rhythm, axis,
  etc.) so that all aspects are reviewed, and no
  findings are missed.

6
Head CT

• The intent of this session is to introduce a
  similar systematic method of cranial CT
  interpretation, based on the mnemonic

7
Head CT

• Blood Can Be Very Bad

8
Blood Can Be Very Bad

• Blood
• Cisterns
• Brain
• Ventricles
• Bone

9
Blood Can Be Very Bad

• Blood
• Cisterns
• Brain
• Ventricles
• Bone

10
Blood Can Be Very Bad

• Blood
• Cisterns
• Brain
• Ventricles
• Bone

11
Blood Can Be Very Bad

• Blood
• Cisterns
• Brain
• Ventricles
• Bone

12
Blood Can Be Very Bad

• Blood
• Cisterns
• Brain
• Ventricles
• Bone

13
CT Scan Basics

• A CT image is a computer-generated picture based
  on multiple x-ray exposures taken around the
  periphery of the subject.
• X-rays are passed through the subject, and a
  scanning device measures the transmitted
  radiation.
• The denser the object, the more the beam is
  attenuated, and hence fewer x-rays make it to the
  sensor.

14
CT Scan Basics

• The denser the object, the whiter it is on CT
• Bone is most dense 1000 Hounsfield U.
• Air is the least dense - 1000H Hounsfield U.

15
CT Scan Basics Windowing
Focuses the spectrum of gray-scale used on a
particular image.
16
2 Sheet Head CT
17
Posterior Fossa

• Brainstem
• Cerebellum
• Skull Base
• Clinoids
• Petrosal bone
• Sphenoid bone
• Sella turcica
• Sinuses

18
CT Scan
19
CT Scan
20
Sagittal View
C Circummesencephalic Cistern
21
CT Diagnostics

• Where is the most sensitive area to examine the
  CT for increased ICP?
• Lateral Ventricles
• IVth ventricle
• Basilar Cisterns
• Gyral pattern

22
Cisterns
23
CT Scan
24
Brainstem Lateral View
25
2nd Key Level Sagittal View
2nd Key Level
Circummesencephalic Cistern
26
Cisterns at Cerebral Peduncles Level
27
CT Scan
28
Suprasellar Cistern
29
CT Diagnostics

• Where is the most sensitive area to examine the
  CT for ventricular dilation?
• IIIrd ventricle
• IVth ventricle
• Temporal horns of lateral ventricles

30
CT Scan
31
3rd Key Level Sagittal View
Circummesencephalic Cistern
32
Cisterns at High Mid-Brain Level
33
CT Scan
34
Ventricles
35
CSF Production

• Produced in choroid plexus in the lateral
  ventricles ? Foramen of Monroe ? IIIrd Ventricle
  ? Acqueduct of Sylvius ? IVth Ventricle ?
  Lushka/Magendie
• 0.5-1 cc/min
• Adult CSF volume is approx. 150 ccs.
• Adult CSF production is approx. 500-700 ccs per
  day.

36
CT Scan
37
CT Scans
Andrew D. Perron, MD, FACEP
37
38
A Few Kid-Specific Thoughts
39
A Few Kid-Specific Thoughts

• Premature Infants (30-34 weeks)
• Larger sylvian, basilar (circummesencephalic)
  cisterns.
• Larger subarachnoid spaces
• Thin cerebral cortex (Gray matter)
• Prominent white matter (with higher water
  content)
• Limited cortical gyral pattern
• Ventricles are variable slit-like to
  well-developed
• Term Infant (36-41 weeks)
• Small, slit-like lateral ventricles
• Continued white-matter prominence
• More prominent sulcal pattern
• Temporal horns unlikely to be seen
• 1st 2nd years of Life
• Marked growth of all lobes of the brain
  (proportionally greatest in frontal lobes)
• Wide variation in lateral ventricle size (3rd
  and 4th fairly constant)
• Temporal horns unlikely to be seen.

40
1 day 1 year 2 years
Andrew D. Perron, MD, FACEP
40
41
Trauma Pictures
42
B is for Blood

• 1st decision Is blood present?
• 2nd decision If so, where is it?
• 3rd decision If so, what effect is it having?

43
CT Diagnostics

• At what point does blood become isodense with
  brain?
• About 48 hours
• About 1 week
• About 2 weeks
• After 1 month

44
B is for Blood

• Acute blood is bright white on CT (once it clots).

• Blood becomes isodense at approximately 1 week.

• Blood becomes hypodense at approximately 2 weeks.

45
B is for Blood

• Acute blood is bright white on CT (once it clots).

• Blood becomes isodense at approximately 1 week.

• Blood becomes hypodense at approximately 2 weeks.

46
B is for Blood

• Acute blood is bright white on CT (once it clots).

• Blood becomes isodense at approximately 1 week.

• Blood becomes hypodense at approximately 2 weeks.

47
Epidural Hematoma

• Lens shaped
• Does not cross sutures
• Classically described with injury to middle
  meningeal artery
• Low mortality if treated prior to unconsciousness

• (

48
CT Scans
49
Subdural Hematoma

• Typically falx or sickle-shaped.
• Crosses sutures, but does not cross midline.
• Acute subdural is a marker for severe head
  injury. (Mortality approaches 80)
• Chronic subdural usually slow venous bleed and
  well tolerated.

50
CT Scan
Andrew D. Perron, MD, FACEP
50
51
Subarachnoid Hemorrhage
52
Subarachnoid Hemorrhage

• Blood in the cisterns/cortical gyral surface
• Aneurysms responsible for 75-80 of SAH
• AVMs responsible for 4-5
• Vasculitis accounts for small proportion (
• No cause is found in 10-15
• 20 will have associated acute hydrocephalus

53
CT Diagnostics

• What is the sensitivity of CT for SAH?
• 100
• 95
• 80
• DependsI need a lot more information to answer.

54
CT Scan Sensitivity for SAH

• 98-99 at 0-12 hours
• 90-95 at 24 hours
• 80 at 3 days
• 50 at 1 week
• 30 at 2 weeks
• Depends on generation of scanner and who is
  reading scan and how much blood there is.

55
CT Scan
Andrew D. Perron, MD, FACEP
55
56
CT Scan
Andrew D. Perron, MD, FACEP
56
57
Intraventricular/Intraparenchymal Hemorrhage
58
CT Scan
Andrew D. Perron, MD, FACEP
58
59
C is for CISTERNS
(Blood Can Be Very Bad)

• 4 key cisterns
• Circummesencephalic
• Suprasellar
• Quadrigeminal
• Sylvian

Circummesencephalic
60
Cisterns

• 2 Key questions to answer regarding cisterns
• Is there blood?
• Are the cisterns open?

61
Andrew D. Perron, MD, FACEP
61
62
Andrew D. Perron, MD, FACEP
62
63
Andrew D. Perron, MD, FACEP
63
64
B is for BRAIN
(Blood Can Be Very Bad)
65
Andrew D. Perron, MD, FACEP
65
66
Tumor
Andrew D. Perron, MD, FACEP
66
67
Atrophy
Andrew D. Perron, MD, FACEP
67
68
CT Diagnostics

• What percentage of mass lesions will require IV
  contrast to be identified?
• 100
• 50
• 30-40
• 10-20

69
Abscess
Andrew D. Perron, MD, FACEP
69
70
Hemorrhagic Contusion
Andrew D. Perron, MD, FACEP
70
71
Andrew D. Perron, MD, FACEP
71
72
Mass Effect
Andrew D. Perron, MD, FACEP
72
73
Stroke
Andrew D. Perron, MD, FACEP
73
74
Intracranial Air
75
Intracranial Air
Andrew D. Perron, MD, FACEP
75
76
Intracranial Air
Andrew D. Perron, MD, FACEP
76
77
V is for VENTRICLES
(Blood Can Be Very Bad)
78
Andrew D. Perron, MD, FACEP
78
79
Andrew D. Perron, MD, FACEP
79
80
Ex-Vacuo Phenomenon
Andrew D. Perron, MD, FACEP
80
81
Andrew D. Perron, MD, FACEP
81
82
Andrew D. Perron, MD, FACEP
82
83
Andrew D. Perron, MD, FACEP
83
84
BONE
Andrew D. Perron, MD, FACEP
84
85
Andrew D. Perron, MD, FACEP
85
86
Andrew D. Perron, MD, FACEP
86
87
Andrew D. Perron, MD, FACEP
87
88
Andrew D. Perron, MD, FACEP
88
89
Blood Can Be Very Bad
If no blood is seen, all cisterns are present and
open, the brain is symmetric with normal
gray-white differentiation, the ventricles are
symmetric without dilation, and there is no
fracture, then there is no emergent diagnosis
from the CT scan.
90
RIP
91
Questions
www.ferne.orgferne_at_ferne.orgAndrew D. Perron,
MD, FACEP perroa_at_mmc.org(207) 662-7015
