Title: ENDOTRACHEAL INTUBATION


1
ENDOTRACHEAL INTUBATION
  • Thida Ua-kritdathikarn, MD.
  • Department Of Anesthesiology
  • Faculty of medicine, PSU

2
(No Transcript)
3
(No Transcript)
4
Indication for endotracheal intubation
  • 1) For supporting ventilation in patient with
    some pathologic disease

Upper airway obstruction
Respiratory failure
Loss of conciousness
5
Indication for endotracheal intubation (cont)
  • 2) For supporting ventilation during general
    anesthesia
  • Type of surgery

Operative site near the airway
  • Abdominal or thoracic surgery

6
Indication for endotracheal intubation (cont)
Prone or lateral position
Long period of surgery
  • Patient has risk of pulmonary aspiration
  • Difficult mask ventilation

7
(No Transcript)
8
AIRWAY ASSESSMENTS
  • 1) Condition that associated with difficult
    intubation
  • Congenital anomalies ---gt Pierre Robin syndrome
    , Downs syndrome
  • Infection in airway--gt Retropharyngeal abscess,
    Epiglottitis
  • Tumor in oral cavity or larynx

9
AIRWAY ASSESSMENT
  • 1) Condition that associated with difficult
    intubation (cont)
  • Enlarge thyroid gland
  • trachea shift to lateral or compressed tracheal
    lumen

10
AIRWAY ASSESSMENT
1) Condition that associated with difficult
intubation (cont)
  • Maxillofacial ,cervical or laryngeal trauma
  • Temperomandibular joint dysfunction
  • Burn scar at face and neck
  • Morbidly obese or pregnancy

11
AIRWAY ASSESSMENT
  • 2) Interincisor gap normal -gt more than 3 cms

12
AIRWAY ASSESSMENT
  • 3) Mallampati classification Class 3,4 -gt may be
    difficult intubation

13
AIRWAY ASSESSMENT
Laryngoscopic view
  • grade 3,4 -gt risk for difficult intubation

14
AIRWAY ASSESSMENT
  • 4) Thyromental distance more than 6 cms

15
AIRWAY ASSESSMENT
  • 5) Flexion and extension of neck

16
AIRWAY ASSESSMENT
  • 6) Movement of temperomandibular joint (TMJ)

Grinding
17
Equipment preparation
18
  • 1) Laryngoscope handle and blade

19
LARYNGOSCOPIC BLADE
  • Macintosh (curved) and Miller (straight) blade
  • Adult Macintosh blade, small children Miller
    blade

20
  • 2) Endotracheal tube

21
Endotracheal tube
  • 1) Size of endotracheal tube internal diameter
    (ID)
  • Male ID 8.0 mms . Female ID 7.5 mms
  • New born - 3 months ID 3.0 mms
  • 3-9 months ID 3.5 mms
  • 9-18 months ID 4.0 mms
  • 2- 6 yrs ID (Age/3)
    3.5
  • gt 6 yrs ID (Age/4)
    4.5

22
  • 2) Material Red rubber or PVC
  • 3) Endotracheal tube cuff

23
  • 4) Bevel
  • 5) Murphys eye

24
  • 6) Depth of endotracheal tube Midtrachea or
    below vocal cord 2 cms
  • Adult -gt Male 23 cms ,Female 21 cms
  • Children

  • Oral endotracheal tube (Age/2) 12
    (cm)
  • Nasal endotracheal tube (Age/2) 15 (cm)

25
  • 7) Tube markings
  • Z-79
  • Disposible (Do not reuse)
  • Oral/ Nasal
  • Radiopaque marker

26
3) Other equipments
  • 3.1 Stylet

27
  • 3.2 Oropharyngeal or nasopharyngeal airway

28
  • 3.3) Suction catheter
  • 3.4) Slip joint

29
  • 3.5) Face mask and self inflating bag
  • 3.6) Magill forcep

30
  • 3.7) Syringe
  • 3.8) Lubricating jelly
  • 3.9) Plaster for strap endotracheal tube
  • 4. Monitoring success of endotracheal intubation
  • 4.1) Stethoscope
  • 4.2) Endtidal - CO2
  • 4.3) Pulse oximeter

31
Sniffing position
  • Flexion at lower cervical spine
  • Extension at atlanto-occipital joint

32
Sniffing position
33
Steps of oroendotracheal intubation
34
Steps of oroendotracheal intubation
35
Steps of oroendotracheal intubation
Vareculla
36
Steps of oroendotracheal intubation
37
Steps of oroendotracheal intubation
38
Nasoendotracheal intubation
39
Nasoendotracheal intubation
  • Advantage
  • 1) Comfortable for prolong intubation in
    postoperative period
  • 2) Suitable for oral surgery tonsillectomy ,
    mandible surgery
  • 3) For blind nasal intubation
  • 4) Can take oral feeding
  • 5) Resist for kinking and difficult to accidental
    extubation

40
Disadvantage
  • 1) Trauma to nasal mucosa
  • 2) Risk for sinusitis in prolong intubation
  • 3) Risk for bacteremia
  • 4) Smaller diameter than oral route -gt difficult
    for suction

41
Contraindication for nasoendotracheal intubation
  • 1) Fracture base of skull
  • 2) Coagulopathy
  • 3) Nasal cavity obstruction
  • 4) Retropharyngeal abscess

42
Complication of endotracheal intubation
  • 1) During intubation
  • Trauma to lip, tongue or teeth
  • Hypertension and tachycardia or arrhythmia
  • Pulmonary aspiration
  • Laryngospasm
  • Bronchospasm

43
Complication of endotracheal intubation (Cont)
  • 1) During intubation
  • Laryngeal edema
  • Arytenoid dislocation -gt hoarseness
  • Increased intracranial pressure
  • Spinal cord trauma in cervical spine injury
  • Esophageal intubation

44
Complication of endotracheal intubation(Cont)
2) During remained intubation
Obstruction from klinking , secretion or
overinflation of cuff Accidental extubation
or endobronchial intubation Disconnection
from breathing circuit
45
Complication of endotracheal intubation(Cont)
  • 2) During remained intubation
  • Pulmonary aspiration
  • Lib or nasal ulcer in case with prolong period
    of intubation
  • Sinusitis or otitis in case with prolong
    nasoendotracheal intubation

46
Complication of endotracheal intubation(Cont)
  • 3) During extubation
  • Laryngospasm
  • Pulmonary aspiration
  • Edema of upper airway

47
Complication of endotracheal intubation(Cont)
  • 4) After extubation
  • Sore throat
  • Hoarseness
  • Tracheal stenosis (Prolong intubation)
  • Laryngeal granuloma
