Title: STM in Managed Runtimes: HighLevel Language Semantics MICRO 07 Tutorial


1
STM in Managed Runtimes High-Level Language
Semantics(MICRO 07 Tutorial)
  • Dan Grossman
  • University of Washington
  • 2 December 2007

2
So
  • Hopefully youre convinced high-level language
    semantics is needed for transactions to succeed
  • First session focus on various notions of
    isolation
  • A taxonomy of ways weak isolation can surprise
    you
  • Ways to avoid surprises
  • Strong isolation
  • Restrictive type systems
  • Second session
  • Formal model for high-level definitions
    correctness proofs
  • Memory-model problems
  • Integrating exceptions, I/O, and multithreaded
    transactions


3 slide review
3
Notions of isolation
  • Strong-isolation A transaction executes as
    though no other computation is interleaved
  • Weak-isolation?
  • Single-lock (weak-sla) A transaction executes
    as though no other transaction is interleaved
  • Single-lock abort (weak undo) Like weak-sla,
    but a transaction can abort/retry, undoing
    changes
  • Single-lock lazy update (weak on-commit)
    Like weak-sla, but buffer updates until commit
  • Real contention Like weak undo or weak
    on-commit, but multiple transactions can run at
    once
  • Catch-fire Anything can happen if theres a race

4
Partition
  • Surprises arose from the same mutable locations
    being used inside outside transactions by
    different threads
  • Hopefully sufficient to forbid that
  • But unnecessary and probably too restrictive
  • Bans publication and privatization
  • cf. STM Haskell PPoPP05
  • For each allocated object (or word), require one
    of
  • Never mutated
  • Only accessed by one thread
  • Only accessed inside transactions
  • Only accessed outside transactions

5
Static partition
  • Recall our what is a race problem

initially x0, y0, z0
atomic if(xlty) z
atomic x y
r z //race? assert(z0)
  • So accessed on valid control paths is not
    enough
  • Use a type system that conservatively assumes all
    paths are possible

6
So
  • Hopefully youre convinced high-level language
    semantics is needed for transactions to succeed
  • First session focus on various notions of
    isolation
  • A taxonomy of ways weak isolation can surprise
    you
  • Ways to avoid surprises
  • Strong isolation
  • Restrictive type systems
  • Second session
  • Formal model for high-level definitions
    correctness proofs
  • Memory-model problems
  • Integrating exceptions, I/O, and multithreaded
    transactions

7
Why formal models
  • Some really smart people didnt anticipate the
    surprises
  • So maybe there are other surprises even with the
    partitioning type system
  • Increase our confidence by modeling
    (mini-languages) various forms of isolation and
    prove them equivalent given the type system
  • So far weak-sla, weak undo
  • Future work weak on-commit, real contention,
    thread-local, immutable

8
A formal program state
  • a H e1 en
  • e a thread (an expression that runs and
    terminates)
  • H a heap (maps mutable labels to values)
  • a either ?o or ?
  • ? means one thread is in a transaction
  • o means no thread is in a transaction
  • A high-level model for programmers
    compiler-writers
  • No TM implementation details!

9
Operational semantics
  • Execution is a series of steps from one state to
    another
  • At each step, one thread runs some instruction
  • aHe1 en aHe1 en
  • Isolation amounts to using the a to restrict
    interleavings
  • strong If a ?, only the transaction can touch
    H
  • weak-sla If a ?, no other thread can start a
    transaction
  • weak undo Like weak-sla, but transactions log
    updates and can abort/retry by undoing them
  • a returns to o after the abort is complete

10
A family of languages
  • So strong, weak-sla, and weak undo are
    similar languages with different semantic rules
  • The AtomsFamily ?
  • Lots of Greek letters in the paper
  • Theorem
  • If e1, , en type-check with our partition
    rules, then
  • the set of states reachable from aHe1
    en
  • is the same for strong, weak-sla, and weak
    undo.
  • Not quite, weak undo has more transient states
    and can produce more garbage

11
Type-checking
  • Code can be used inside transactions, outside
    transactions, or both
  • Each memory location can be accessed only inside
    transactions or only outside transactions
  • Form of type-checking
  • ? ot wt both
  • ? int ??
  • ? ?, x?
  • ? ? e ?
  • Assuming variables in ? have those types, e has
    type ? and stays on the side of the partition
    required by ?

12
Type-checking
  • ? ? e ?
  • Assuming variables in ? have those type, e has
    type ? and stays on the side of the partition
    required by ?
  • Three example rules (C-style syntax)
  • (specialized slightly to emphasize the
    partition)
  • ?(x) ?? ? ? e ??
  • ? ? x ?? ? ? e ?
  • ? wt e ?
  • ? ? atomice ?

13
The proof
  • The proofs are dozens of pages and a few
    person-months (lest a skipped step hold a
    surprise)
  • But the high-level picture is illuminating

14
The proof
  • The proofs are dozens of pages and a few
    person-months (lest a skipped step hold a
    surprise)
  • But the high-level picture is illuminating
  • If possible in strong, then possible in weak-sla
  • trivial dont ever violate isolation

strong
weak-sla
weak undo
15
The proof
  • The proofs are dozens of pages and a few
    person-months (lest a skipped step hold a
    surprise)
  • But the high-level picture is illuminating
  • If possible in weak-sla, then possible in weak
    undo
  • trivial dont ever abort

strong
weak-sla
weak undo
16
The proof
  • The proofs are dozens of pages and a few
    person-months (lest a skipped step hold a
    surprise)
  • But the high-level picture is illuminating
  • If possible in weak-sla, then possible in strong
  • Current transaction is serializable thanks to the
    type system (can permute with other threads)
  • Earlier transactions serializable by induction

strong
weak-sla
weak undo
17
The proof
  • The proofs are dozens of pages and a few
    person-months (lest a skipped step hold a
    surprise)
  • But the high-level picture is illuminating
  • If possible in weak undo, then possible in
    weak-sla?
  • Really need that abort is correct
  • And thats hard to show, especially with
    interleavings from weak isolation

strong
weak-sla
weak undo
18
The proof
  • The proofs are dozens of pages and a few
    person-months (lest a skipped step hold a
    surprise)
  • But the high-level picture is illuminating
  • If possible in weak undo, then possible in
    weak-sla?
  • Define strong undo for sake of the proof
  • Can show abort is correct without interleavings

strong undo
strong
weak-sla
weak undo
19
Why we formalize, redux
  • Thanks to the formal semantics, we
  • Had to make precise definitions
  • Know we did not skip cases (at least in the
    model)
  • Learned the essence of why the languages are
    equivalent under partition
  • Weak interleavings are serializable
  • Abort is correct
  • And these two arguments compose

20
So
  • Hopefully youre convinced high-level language
    semantics is needed for transactions to succeed
  • First session focus on various notions of
    isolation
  • A taxonomy of ways weak isolation can surprise
    you
  • Ways to avoid surprises
  • Strong isolation
  • Restrictive type systems
  • Second session
  • Formal model for high-level definitions
    correctness proofs
  • Memory-model problems
  • Integrating exceptions, I/O, and multithreaded
    transactions

21
Relaxed memory models
  • Modern languages dont provide sequential
    consistency
  • Lack of hardware support
  • Prevents otherwise sensible ubiquitous compiler
    transformations (e.g., copy propagation)
  • So safe languages need two complicated
    definitions
  • What is properly synchronized?
  • What can compiler and hardware do with bad
    code?
  • (Unsafe languages need (1))
  • A flavor of simplistic ideas and the consequences

22
Ordering
  • Can get strange results for bad code
  • Need rules for what is good code

initially x0 and y0
x 1 y 1
r y s x assert(sgtr)//invalid
23
Ordering
  • Can get strange results for bad code
  • Need rules for what is good code

initially xy0
initially x0 and y0
x 1 sync(lk) y 1
r y sync(lk) //same lock s
x assert(sgtr)//valid
24
Ordering
  • Can get strange results for bad code
  • Need rules for what is good code

initially x0 and y0
x 1 atomic y 1
r y atomic s x assert(sgtr)//???
If this is good code, existing STMs are wrong
25
Ordering
  • Can get strange results for bad code
  • Need rules for what is good code

initially x0 and y0
x 1 atomicz1 y 1
r y atomictmp0z s x assert(sgtr)//???
Conflicting memory a slippery ill-defined slope
26
Lesson
  • It is not clear when transactions are ordered,
    but languages need memory models
  • Corollary This could/should delay adoption of
    transactions in well-specified languages
  • I wish I had more answers. ?

27
Other operations
  • So far every atomic block we have considered
    only
  • read/wrote/allocated memory
  • called functions
  • What about
  • I/O
  • Exceptions (or first-class continuations)
  • Spawn a thread

28
I/O
  • Cant have irreversible actions in
  • transactions that might abort
  • Need pragmatic, partial solutions such as
  • Forbid irreversible actions in transactions
  • Trivial extension of our partition type system
  • Have unabortable transactions
  • Make actions reversible
  • Buffer output
  • Buffer (idempotent) input

29
I After O
  • The real problem is input after output in a
    transaction

atomic write_to_file() read_from_file()
Contents read cannot depend on how external world
sees write if the write is buffered
30
Native mechanism
  • Can generalize Require native code to have 2
    versions
  • Runtime calls 1 in transactions, 1 not in
    transactions
  • Native code responsible for 2 versions the same
  • Transactional versions also need callbacks for
    pre-commit, post-commit, and pre-abort
  • Sufficient for buffering input and output
  • Sufficient for external transaction systems
  • If in transaction version causes abort, that
    just encodes safe dynamic failure/retry

31
Exceptions
  • If code in atomic throws exception to outside
    atomic
  • A. Does the transaction commit or abort?
  • B. Where does control transfer to?
  • Three obvious answers
  • 1. Commit transaction, transfer to exception
    handler
  • My preference exceptions in most HLLs are
    semantically just non-local jumps
  • Preserves design goal that atomic has no effect
    on single-threaded programs

32
Exceptions
  • If code in atomic throws exception to outside
    atomic
  • A. Does the transaction commit or abort?
  • B. Where does control transfer to?
  • Three obvious answers
  • 2. Abort transaction, transfer to retry the
    exception
  • Turns exceptions into aborts
  • Useful if exceptions due to shared-memory state
  • But programmer can encode this

atomic try s catch (Throwable e)
abort
33
Exceptions
  • If code in atomic throws exception to outside
    atomic
  • A. Does the transaction commit or abort?
  • B. Where does control transfer to?
  • Three obvious answers
  • 3. Abort transaction, transfer to exception
    handler
  • But the transaction never happened?!
  • What if the exception value uses memory
    allocated/written by the aborted transaction?!

34
Beyond exceptions
  • Other non-local jumps even harder to deal with
  • Example Perhaps a coroutine jumps out of an
    atomic and then jumps back in
  • Then probably the jump out should continue the
    transaction (commit or abort) later
  • It depends what youre trying to do which is a
    problem if the same language feature (exceptions,
    continuations, etc.) is used for multiple idioms.
  • Tough policy questions mechanism pretty easy

35
Multithreaded transactions
  • What if code in atomic creates a new thread?
  • Easy answers
  • Dynamic failure
  • Thread not runnable unless/until transaction
    commits
  • More interesting
  • Parallelism within transaction
  • Isolation and concurrency are orthogonal
  • Controversial(?) claim Necessary due to Amdahls
    Law as core-count increases

36
Multithreaded transactions
  • (Semantics done implementation is work in
    progress)
  • When does multithreaded transaction commit?
  • After all spawned threads terminate
  • What is hard for programmers?
  • Nested transactions now crucial for isolating
    parallel computations inside a larger transaction
  • What is hard for implementors?
  • Transactional bookkeeping must be parallel
  • Unclear how hardware could best help

37
So
  • Hopefully youre convinced high-level language
    semantics is needed for transactions to succeed
  • First session focus on various notions of
    isolation
  • A taxonomy of ways weak isolation can surprise
    you
  • Ways to avoid surprises
  • Strong isolation
  • Restrictive type systems
  • Second session
  • Formal model for high-level definitions
    correctness proofs
  • Memory-model problems
  • Integrating exceptions, I/O, and multithreaded
    transactions

38
If I had another 2 hours
  • Plenty more semantics to consider
  • Open-nesting semantics
  • Message-passing within transactions
  • See recent work from Oregon, Purdue, UW
  • atomic s1 orelse s2
  • Try s2 if s1 aborts
  • Fairness guarantees
  • Obstruction-freedom

39
Conclusions
  • Weak isolation without type restrictions is
    surprising
  • Interaction with other language features
    non-trivial
  • PL-style semantics has a huge role to play in
    bringing transactions to high-level languages
  • An essential complement to the core algorithms,
    compiler, hardware work
  • Need cross-cultural understanding of the issues

wasp.cs.washington.edu
Write a Comment
User Comments (0)
About PowerShow.com
