Automatic Caption Localization in Compressed Video

1
Automatic Caption Localization in Compressed Video

• By Yu Zhong, Hongjiang Zhang, and Anil K. Jain,
  Fellow, IEEE
• IEEE Transactions on Pattern Analysis and Machine
  Intelligence
• Vol 22, No. 4, April 2000

2
Introduction

• Caption text on video
• General methods for caption extraction
• Proposed Method
• How it works
• Evaluation

3
Caption Text on Video

• Parse, index and abstract of Video
• Caption Text
• Information of Video
• Describe the content
• Catch highlights

4
General Extraction Methods

• Component-based
• Geometrical arrangement
• Homogeneous color
• Texture-based
• Contrast the background
• Horizontal intensity variation

5

• Most published method
• Applied on uncompressed images
• Digital video and images
• Compressed (MPEG JPEG)
• DCT (Discrete Cosine Transform) coding
• Reducing interframe redundancy (for MPEG)

6
Proposed Method

• Step 1 2
• Detecting Blocks
• Step 3
• Refinement
• Step 4
• Segmentation of rows

Step 1
Step 2
Step 3
Step 4
7
Proposed Method
Source frame
8
Step 1 2Detecting Blocks of High Horizontal
Spatial Intensity Variation

• Operates in DCT domain
• Not necessary to decompress
• Unit 8x8 blocks in I-frames (Intracoded)
• Quantized DCT coefficients
• Readily extracted
• Fast

DCT blocks with high horizontal intensity
variation
9
Step 3Remove noise by applying Morphological
Operations

• Step 1 2
• Picked high contrast nontext blocks
• Disconnected text blocks
• Wide spacing, low contrast, large fonts
• Step 3
• Remove most isolated blocks
• Merges nearby blocks

Applying Morphological Operations
10
Step 4Segmentation based on vertical intensity
variation

• Detected text regions
• Large vertical intensity variation
• Local vertical harmonics
• Corresponding row of text
• High vertical spectrum energy

After horizontal/vertical text energy test
11
Dilating the previous result by one block
12
Evaluation

• Not work properly when
• Very big characters
• Too widely spaced text
• Image texture

13
Caption Text on Video

• Parse, index and abstract of Video
• Caption Text
• Information of Video
• Describe the content
• Catch highlights

14
Evaluation

• Commonly used caption
• NOT very big characters
• NOT too widely spaced text
• NOT image texture
• Therefore, important information retrieved!

15
Evaluation

• Future work
• Proposed to other transform-based compressions
• Use also color information to improve accuracy
• Combining DCT blocks to support larger fonts
• Solution to P- and B-frames

16
Summary

• Proposed caption localization method
• For compressed video
• Fast
• Further development is needed to improve
• Accuracy
• Support other compression methods
