Workpackage 3: Automatic Performance Analysis and Grid Computing

1
Workpackage 3Automatic Performance Analysisand
Grid Computing

• Peter Kacsuk
• Laboratory of Parallel and Distributed Systems
• MTA SZTAKI Research Institute
• kacsuk_at_sztaki.hu
• www.lpds.sztaki.hu

2
Contents

• Goals of monitoring in a grid
• Task 3.1 Requirement for performance analysis
• Task 3.2 Performance monitoring and performance
  data access (Grid Monitoring Architecture)
• Task 3.3 Automatic performance analysis and grid
  computing
• Conclusions

3
Goals of grid monitoring

• The question is
• not how to measure resources (inherit old good
  solutions)
• but how to deliver information to end-users and
  system/grid administrators
• Status information
• Inform users/ administrators about the grid and
  applications
• available resources
• status and progress of applications
• Propagate errors to users/management
• Performance monitoring to
• tune the application,
• use the grid more efficiently

4
Task 3.1 Requirement for performance analysis
Differences between high performance computers
and the grid
Grid (performance) monitoring scenarios
5
Differences

• Complex distributed system ? often observe
  unexpectedly low performance
• Where is the bottleneck?
• application
• operating system
• disks
• network adapters on either the sending or the
  receiving host
• network switches, routers
• Experience of the Netlogger group
• 40 network, 40 application, 20 host problems
• application 50 client, 50 server process
  problems

6
Differences

• Dynamic environment with
• many computing resources
• many services
• many users
• many single jobs
• many distributed applications gt SCALABILITY
• World-wide distributed environment with
• high latency
• frequent faults
• very heterogeneous resources
• Security (authentication, authorisation, encoding)

7
Scenario 1 (S5 of GGF)

• Fault detection and analysis, heartbeats
• monitoring data is used to determine faults in
  system components and applications
• monitoring data could also be used to find the
  cause of the faults
• requirements
• push model data delivery
• heartbeat events are valid only for a short time
  interval and should be delivered in this time
  constraint

8
HeartBeat
Application Level Fault Handler
!
System Monitoring Tools
Process and Host Heartbeat
Process and Host Heartbeat
Host 2
Host 1
Process Status Inquiry
Process Status Inquiry
Register/ Unregister
Register/ Unregister
9
Scenario 2 (S6)

• Job status/progress monitoring
• determine if a job is running, has died or hung
• follow the status of long running jobs
• requirements
• pull model data delivery
• per job data
• problems
• finding the processes that belong to a job
  either the jobs should identify themselves or we
  need an interface to the scheduler to get this
  information

10
Scenario 3 (S1, S13)

• Application performance monitoring
• determine performance characteristics of an
  application
• real-time visualisation of events
• requirements
• push model data delivery
• large volume of data in real-time
• data archival for off-line analysis
• user defined event types

11
Scenario 3 (cont.)

• requirements (cont.)
• remote data processing (statistics, data
  reduction)
• dynamic sensor management
• problems
• finding the right producers before the
  application is started (start-up problem)
• remote data reduction from list, scripts,
  plug-ins
• level of sensor control enable/disable,
  parameters

12
Start-up procedure
scheduler
job manager
LAN
WAN
application process2
application process1
Local Monitor
Local Monitor
13
Scenario 4 (S7)

• Performance analysis of distributed systems
• locate performance bottlenecks in complex
  distributed systems
• requirements (in addition to the requirements of
  scenario 3)
• very large volume of data from many different
  sources in real-time
• accurate and consistent measurements
• accurate cross-site timestamps
• comparable data from different sources

14
Scenario 4 (cont.)

• problems
• time synchronisation (use NTP?)
• data accuracy error bounds should be provided,
  sensors should be able to limit their impact on
  the monitored systems
• data consistency measurements should be
  co-ordinated (producers may need to communicate)

15
Scenario 5 (S10, S8, S14)

• Scheduling services, self tuning applications
• determine the optimal resources for a job
• applications could use monitoring data to adapt
  themselves to the current situation
• requirements
• pull model data delivery
• accurate usage/availability information from all
  computing resources in the grid
• freshness of data is critical
• availability of accurate forecasted data is
  desirable

16
Scenario 5 (cont.)

• problems
• gathering current measurements from all resources
• forecasting needs archives maybe consumers
  should be able to announce themselves as well to
  allow producers to discover demands

17
Scenario 6 (S9)

• Data replication services
• data is replicated at or migrated to different
  places to optimise access time
• monitoring might be used to identify stale
  replicas
• requirements
• pull model data delivery
• current available space measurements from all
  storage devices
• data access patterns of applications
• network measurements (preferably forecasted)

18
Scenario 6 (cont.)

• problems
• network topology information is needed
• Should the Grid Information System (GIS) contain
  this information?
• Should monitoring services be involved in
  discovering this information?

19
Scenario 7 (S11)

• Accounting and auditing
• account for resource utilisation
• verify resource utilisation and level of service
• requirements
• per user or per bank account data
• accuracy of measurement is important
• privacy of data is important
• problems
• privacy Where policies are enforced?

20
Task 3.2 Performance monitoring and performance
data access (Grid Monitoring Architecture)

• Why not use an existing monitoring system?
• Most existing monitors cannot be embedded in
  tools or applications
• Limited fault detection functionality
• System- or application-specific information but
  not both
• Lack of scalable data forwarding and gathering
  mechanisms
• Incompatibility with security and authentication
  requirements of the grid

21
Grid Monitoring Architecture

• Goals
• Develop a general framework for monitoring and
  management
• Monitor and manage a variety of resources,
  services and applications
• Scalable, secure
• Framework should be extensible for specific tasks
• new components for monitoring and performing
  actions
• new logic for management
• modular structure
• Compatible with emerging standards
• to be able to communicate with other systems

22
Existing monitoring tools

• NetLogger
• GRM/PROVE
• Network Weather Service
• Globus HeartBeat Monitor
• Autopilot
• NASA Information Power Grid - monitor
• GGF GMA architecture

23
NetLogger monitoring structure
Local Host
Trace file
Host 1
Host 2
24
NetLogger Toolkit (cont.)

• The NetLogger approach is novel in that it
  combines
• network, host, and application-level monitoring
  to provide a complete view of the entire system.
• Valuable tool for
• isolating and correcting performance bottlenecks
• debugging distributed applications
• selecting hardware components to upgrade (to
  alleviate bottlenecks)

25
NetLogger Toolkit (cont.)

• Disadvantages
• single user tool
• hand-made set up of monitoring session
• not scalable to large systems
• single trace collector process
• each event individually transferred through the
  net
• only push model
• no security

26
GRM/PROVE performance analysis system

• Part of the P-GRADE integrated development
  environment.
• Monitoring and visualising parallel programs at
  GRAPNEL level.
• Portability. Heterogeneous UNIX clusters.
• Ensures evaluation of long-running programs
• Support for debugger in P-GRADE with execution
  visualisation
• Collection of both statistics and event trace
• No lost of trace data at program abortion. The
  execution to the point of abortion can be
  visualised.
• Execution (and monitoring) remotely from the user
  environment

27
Usage Performance Visualization
28
Various Windows in PROVE
29
GRM semi-on-line monitor

• Semi-on-line
• store trace events in local storage (off-line)
• make it available for analysis at any time during
  execution (on-line)
• NO real-time (or fast response) requirements!
• Advantages
• analyse the state (performance) of the
  application at any time
• scalability analyse trace data in smaller
  sections and delete them if they are not longer
  needed
• Less overhead/intrusion to the execution system
  than with on-line collection
• Less stress on the collection side pull model
  instead of push model. Collections initiated only
  from top.

30
Semi-on-line observation
31
GRM-Grid monitoring structure
Local Host
Trace file
Host 1
Host 2
Trace file
32
GRM/PROVE monitoring

• Advantages
• much more scalable than NetLogger
• local data reduction is possible
• Less overhead/intrusion to the execution system
  than in NetLogger
• Less stress on the collection side pull model
  instead of push model. Collections initiated only
  from top.
• Drawbacks
• single user tool
• no security
• no standard data format

33
Network Weather Service

• NWS is a distributed system that
• periodically
• monitors and
• dynamically forecasts the performance of
• various networks and computational resources
• over a given time interval.

34
Network Weather Service

• Components
• Sensors
• network, cpu, memory, disk monitors
• network bandwidth, latency, round-trip time,
  connection time
• Memory
• store event records in flat text files
• each type of events from a sensor in a different
  file
• Name Server
• directory capability used to bind process and
  data names with low-level contact information
  (e.g. address, port).
• LDAP protocol
• Forecaster
• predicts performance data for the future based on
  information stored in Memory components.

35
Network Weather Service
36
Network Weather Service

• Advantages
• scalable for many users and resources using
  several Memory processes to store data
• large network testing and monitoring using clique
  (grouping) technique
• intrusiveness to the monitored system can be kept
  low using passive monitoring techniques (active
  techniques are available as well)
• Forecasting (schedulers need predictions not
  archives!)

37
Network Weather Service

• Disadvantages
• resolution in seconds
• not scalable for frequent monitor information
• no support for application monitoring
• non-standard message format
• query/response model ? no error report
• name server and forecaster are centralized
• no security (changes when Globus GIS will be
  used)

38
HeartBeat Monitor

• Monitors process state (system or application)
  for status report and fault detection.
• Components
• Client library (HBMCL)
• register/unregister process to HBLM
• Local Monitor (HBLM)
• checks status of registered processes on its host
• reports status periodically to HBMDC(s)
• Data Collector (HBMDC)
• receives reports sent by HBLMs and incorporates
  these reports into its local repository
• infers the unavailability or failure of monitored
  components
• calls activation callback functions registered by
  applications for fault management

39
HeartBeat Monitor
40
HeartBeat Monitor

• Advantages
• process status monitoring and fault detection
• scalable for many resources and users
• Disadvantages
• no support for performance monitoring
• non-standard, non-extendible message format

41
NASA IPG monitor

• 3 basic components
• Sensors, actuators, an event service
• Users write monitors and fault managers, with
  help from components provided

Event Service
Monitor
Sensors
Fault Manager
Actuators
42
Actuators

• An actuator performs an action
• Input parameters
• Output parameters
• Common actuator API
• Basic actuators are implemented
• Send email, run application, ...
• Users can implement their own actuators

43
Event Service

• Propagates events from producers to consumers
• Publisher-subscriber paradigm
• Consumers subscribe for events from producers
• Asynchronous delivery of events
• Automatic delivery of events to all interested
  clients
• Request-reply paradigm on the way
• Consumer requests an event, the producer replies
  with it
• Communication
• TCP
• Future UDP, SSL-based authentication and
  encryption
• XML for events and messages
• Publisher and subscriber APIs

44
Higher-Level Components

• Built on three basic components
• Sensor manager
• Manages sensors,subscriptions,and queries
• Directory service
• Hold information about monitors
• Allows managers to find them
• Currently defining
• Expert system (CLIPS)
• Rules for faultmanagement
• Currentlyinvestigating

Directory Service
45
Autopilot

• Autopilot is a distributed performance
  measurement and resource control system that is
  based on the Pablo performance toolkit.
• Its goal is to support monitoring and steering of
  complex distributed applications.

46
Grid Monitoring Architecture

• Global Grid Forum proposal for a new monitoring
  architecture
• Basic building blocks
• sensor
• producer
• consumer
• event directory service
• communication protocols
• event schemes

47
Grid Monitoring Architecture
XML
48
Open questions

• Producer-Consumer event schema and protocols
• GGF propose XML
• Sensors and Producers separated or not?
• Support for application monitoring in the
  proposed architecture
• Steering of systems, applications
• Where and how to store monitoring information?

49
Comparison of Representative Grid Monitoring
Tools

• Report of LPDS, 2000 www.lpds.sztaki.hu
• Comparison metrics
• Scalability
• Intrusiveness
• Validity of Information
• Data format
• Extendebility
• Communication
• Security
• Measurement

50
Conclusion

• Grid is a very complex word-wide distributed
  system with many resources, services and users gt
  conventional approaches are not adequate
• There are many scenarios for monitoring the grid
  (task 3.1)
• Several architecture designs are under
  development, some of them for performance
  analysis (task 3.2)
• No research yet on automatic performance analysis
  in the grid gt Task 3.3 is crucial in the project

51

?
Thank you
